Connecting your Testcontainers integration tests to a remote Docker host
1. OVERVIEW
I have shared how to use Testcontainers to run Spring Boot CosmosDB, and DynamoDB integration tests locally, meaning in your development workstation or laptop.
But what if for licensing reasons, or resources constraints you cannot install Docker Desktop?
What if your organization needs to share specialized testing environments not available locally?
What if your integration tests need to start 3rd party systems to connect to in dedicated build servers as part of your CI/CD pipeline?
This blog post walks you through how to configure a Docker host to allow remote connections, and Testcontainers to use a remote Docker host.
Connecting your Testcontainers integration tests to a remote Docker host
This blog post doesn’t cover installing Docker in a remote host, or using
TLS
to encrypt the Docker daemon connections.
Stay tuned and sign up to the newsletter, I might cover how to secure the Docker Engine
API
in a separate blog post.
2. DOCKER HOST CONFIGURATION
Let’s enable the Docker Engine API
in the remote Docker host.
- Create this folder if it’s not already in the remote Docker host:
sudo mkdir -p /etc/systemd/system/docker.service.d/
- Create or update
/etc/systemd/system/docker.service.d/override.conf
file with:
[Service]
ExecStart=
ExecStart=/usr/bin/dockerd --config-file /etc/docker/daemon.json -H unix:///var/run/docker.sock -H fd:// -H tcp://0.0.0.0:2375
The Docker host will not only listen for local connections via unix:///var/run/docker.sock
, but will also listen for remote connections on tcp://0.0.0.0:2375
.
- Reload the new configuration and restart the remote Docker host
sudo systemctl daemon-reload
sudo systemctl restart docker
The remote Docker host should now be available to process API
requests on port 2375
.
3. TESTCONTAINERS CLIENT CONFIGURATION
Let’s now update the Testcontainers configuration where the Integration Tests will run at.
This could be in your organization’s CI/CD servers, your team’s development workstations or laptops.
- Edit
~/.testcontainers.properties
:
docker.client.strategy=org.testcontainers.dockerclient.EnvironmentAndSystemPropertyClientProviderStrategy
docker.host=tcp://<remote docker host>:2375
EnvironmentAndSystemPropertyClientProviderStrategy Testcontainers class allows the use of environment variables and system properties to try and locate a Docker environment.
In our case, Testcontainers will locate the remote Docker host via the docker.host
configuration property.
4. RUNNING INTEGRATION TESTS
Let’s run the CustomerControllerIntegrationTest from the blog Provisioning DynamoDB tables and seeding data to run Spring Boot Integration Tests.
07:40:33.774 [main] INFO org.testcontainers.dockerclient.DockerClientProviderStrategy -- Found Docker environment with Environment variables, system properties and defaults. Resolved dockerHost=tcp://192.168.1.188:2375
07:40:33.912 [main] INFO org.testcontainers.DockerClientFactory -- Docker host IP address is 192.168.1.188
07:40:33.963 [main] INFO org.testcontainers.DockerClientFactory -- Connected to docker:
Server Version: 28.1.1
API Version: 1.49
Operating System: Debian GNU/Linux 12 (bookworm)
Total Memory: 31893 MB
07:40:34.104 [main] INFO tc.testcontainers/ryuk:0.7.0 -- Creating container for image: testcontainers/ryuk:0.7.0
07:40:35.128 [main] INFO org.testcontainers.utility.RegistryAuthLocator -- Credential helper/store (docker-credential-desktop) does not have credentials for https://index.docker.io/v1/
07:40:35.325 [main] INFO tc.testcontainers/ryuk:0.7.0 -- Container testcontainers/ryuk:0.7.0 is starting: 6ac0ad585d42b0e3b7d7875d818e633a80d337d0060a07f97f5010ab4daaab83
07:40:35.623 [main] INFO tc.testcontainers/ryuk:0.7.0 -- Container testcontainers/ryuk:0.7.0 started in PT1.518985S
07:40:35.633 [main] INFO org.testcontainers.utility.RyukResourceReaper -- Ryuk started - will monitor and terminate Testcontainers containers on JVM exit
07:40:35.633 [main] INFO org.testcontainers.DockerClientFactory -- Checking the system...
07:40:35.634 [main] INFO org.testcontainers.DockerClientFactory -- ✔︎ Docker server version should be at least 1.6.0
07:40:35.654 [main] INFO tc.localstack/localstack:latest -- LOCALSTACK_HOST environment variable set to 192.168.1.188 (to match host-routable address for container)
07:40:35.655 [main] INFO tc.localstack/localstack:latest -- Creating container for image: localstack/localstack:latest
07:40:36.148 [main] INFO tc.localstack/localstack:latest -- Container localstack/localstack:latest is starting: c45978e54470370106a142b2333b239971aea3c2ed0e2728a00073ed38092018
07:40:38.320 [main] INFO tc.localstack/localstack:latest -- Container localstack/localstack:latest started in PT2.664644S
...
The integration test now uses a remote Docker host to run a LocalStack Docker container, according to the log:
Found Docker environment with Environment variables, system properties and defaults. Resolved dockerHost=tcp://asimio-nas.local:2375
5. CONCLUSION
This blog post helped you to configure both, a remote Docker host to allow remote connections, and Testcontainers for your integration tests to use a remote Docker host.
Running Testcontainers in a remote Docker host enhances your org’s testing capabilities.
Thanks for reading and as always, feedback is very much appreciated. If you found this post helpful and would like to receive updates when content like this gets published, sign up to the newsletter.
